F-29A - (OPTIONAL)
Hero Passion Pro(March,2023) · 11 parts
Parts in This Assembly (11)
| Ref # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 80103-AAB-A00 | WIRE HELMET SET | 1 | |
| 2 | 12204-AAF-305 | GUIDE VALVE OVER SIZE | 1 | |
| 3 | 99630-AAC-800 | COVER ASSY. SEAT | 1 | |
| 3 | 99631-AAC-800 | COVER ASSY. SEAT | 1 | |
| 3 | 99639-AAC-800 | COVER ASSY. SEAT | 1 | |
| 3 | 99640-AAC-800 | COVER ASSY. SEAT | 1 | |
| 4 | 99810-AAC-800 | COVER ASSY FUEL TANK | 1 | |
| 5 | 90122-KVT-941 | BOLT BATTERY TERMINAL | 2 | |
| 6 | 90306-KVT-941 | NUT BATTERY TERMINAL | 2 | |
| 7 | 35121-AAF-400 | KEY BLANK NO.1 | 1 | |
| 8 | 35122-AAF-400 | KEY BLANK NO.2 | 1 | |
