F-10-VX - FRONT WHEEL (VX)
Hero Destini 125 (Oct, 2018) · 11 parts
Parts in This Assembly (11)
| Ref # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 42711-AAL-00099 | TYRE | 1 | |
| 1 | 42711-AAL-00199 | TYRE | 1 | |
| 2 | 42753-AAL-001 | RIM,VALVE | 1 | |
| 3 | 44301-AAW-000 | AXLE FR. WHEEL | 1 | |
| 4 | 44311-KPL-900 | COLLAR, FR. WHEEL SIDE | 1 | |
| 5 | K44446AALD200S | KIT, WHEEL COMP. FRONT | 1 | |
| 6 | 44620-KTP-900 | COLLAR, FR. WHEEL DISTANCE | 1 | |
| 7 | 90306-KST-942 | NUT, CASTLE, 12 MM | 1 | |
| 7 | 90306-KTE-911 | NUT, CASTLE, 12 MM | 1 | |
| 8 | 90754-KPL-900 | SEAL, DUST 20 X 32 X 5 | 1 | |
| 9 | 90912-KPL-900 | BEARING BALL RADIAL 6201(U) | 2 | |
