F-5-31-BRAKE HOSE/BRAKE PIPE
HONDALivo CBF110SBK · 9 parts
Parts in This Assembly (9)
| Ref # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 43310-K55-981 | HOSE COMP., RR. BRAKE | 1 | |
| 2 | 45127-K55-980 | PIPE COMP., FR. BRAKE | 1 | |
| 3 | 45128-K55-981 | HOSE COMP. B, FR. BRAKE | 1 | |
| 4 | 45157-K55-980 | CLAMPER B, FR. BRAKE HOSE | 1 | |
| 5 | 46391-SDA-A01 | CLIP G, BRAKE PIPE | 3 | |
| 6 | 90145-GW3-981 | BOLT, OIL, 10X22 | 2 | |
| 7 | 90545-300-000 | WASHER ,OIL BOLT | 4 | |
| 8 | 96001-06016-00 | BOLT, FLANGE SH. 6 X 16 | 1 | |
| 9 | 96001-06025-00 | BOLT, FLANGE, SH. 6 X 25 | 1 |
