F-11 - FRONT FENDER
HONDA GRAZIA SCV125SN · 17 parts
Parts in This Assembly (17)
| Ref # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 33740-KZK-951 | REFLECTOR, FR. SIDE REFLEX | 2 | |
| 2 | 61103-KRY-900 | COLLAR, A FR.FENDER | 3 | |
| 3 | 61110-K1J-D00ZE | FENDER A, FR. *PB123PA* PEARL SIREN BLUE-A | 1 | |
| 3 | 61110-K1J-D00ZF | FENDER A, FR. *NH303M* MAT AXIS GRAY METALLIC | 1 | |
| 3 | 61110-K1J-D00ZM | FENDER A, FR. *R392P* PEARL SPARTAN RED 2 | 1 | |
| 3 | 61110-K1J-D00ZQ | FENDER A, FR. *Y239* MAT CYBER YELLOW | 1 | |
| 4 | 61120-K1J-D00ZA | FENDER B, FR.*NH1* BLACK | 1 | |
| 5 | 61300-K1J-D00 | STAY COMP., FR. FENDER | 1 | |
| 6 | 90111-KPL-900 | BOLT, INNER COVER | 1 | |
| 7 | 90113-KVT-901 | BOLT, SPECIAL HEX., 6X20 | 2 | |
| 8 | 90301-KWN-901 | NUT, U, 5MM(FUJI SEIMITSU)..... | 2 | |
| 9 | 90344-KTE-910 | NUT, CLIP, 4MM | 2 | |
| 10 | 93903-34380 | SCREW, TAPPING, 4X12 | 2 | |
| 11 | 95701-06012-00 | BOLT, FLANGE, 6X12 | 2 | |
| 11 | 95702-06012-00 | BOLT, FLANGE, 6X12 | 2 | |
| 12 | 95701-06020-08 | BOLT, FLANGE, 6X20 | 1 | |
| 12 | 95702-06020-08 | BOLT, FLANGE, 6X20 | 1 | |
