F-1 - HEADLIGHT
HONDA GRAZIA SCV125SN · 9 parts
Parts in This Assembly (9)
| Ref # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 32930-KVT-901 | CLIP B, HARNESS | 1 | |
| 2 | 33100-K1J-D01 | HEADLIGHT ASSY. | 1 | |
| 3 | 33113-MEE-D01 | PIPE, CP | 2 | |
| 4 | 33180-K1J-D01 | LIGHT ASSY., POSITION | 1 | |
| 5 | 90116-KVB-900 | BOLT, FLANGE, 6MM | 2 | |
| 6 | 90116-SP0-003 | CLIP, BUMPER SEAL | 2 | |
| 7 | 93903-24410 | SCREW, TAPPING, 4X16 | 3 | |
| 8 | 93903-35310 | SCREW TAPPING 5X16 | 4 | |
| 9 | 93913-14120 | SCREW, TAPPING, 4X10 | 1 | |
