F-9 - STEERING HANDLE/HANDLE COVER
HONDA GRAZIA SCV125SL · 14 parts
Parts in This Assembly (14)
| Ref # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 53100-K1J-D10 | HANDLE COMP., STEERING | 1 | |
| 1 | 53100-K1J-D00 | HANDLE COMP., STEERING | 1 | |
| 2 | 53124-KWP-900 | COLLAR HANDLE SET | 1 | |
| 3 | 53205-K1J-D00 | COVER, FR. HANDLE | 1 | |
| 4 | 53207-K1J-D00ZC | GARNISH, HANDLE COVER *R392P* PEARL SPARTAN RED 2 | 1 | |
| 4 | 53207-K1J-D00ZE | GARNISH, HANDLE COVER *PB123PA* PEARL SIREN BLUE-A | 1 | |
| 4 | 53207-K1J-D00ZF | GARNISH, HANDLE COVER *NH303M* MAT AXIS GRAY METALLIC | 1 | |
| 4 | 53207-K1J-D00ZL | GARNISH, HANDLE COVER *Y239* MAT CYBER YELLOW | 1 | |
| 5 | 53209-K0L-D00ZA | CAP, STARTER SWITCH *NH1* BLACK | 1 | |
| 6 | 53209-K1J-D00 | VISOR, METER | 1 | |
| 7 | 53250-K1J-D00ZA | COVER COMP., HANDLE RR. *NH1* BLACK | 1 | |
| 9 | 86150-KWS-601 | EMBLEM, PRODUCT(SJS) | 1 | |
| 13 | 90502-KWP-900 | COLLAR B HNDL SET | 1 | |
| 18 | 95802-10055-08 | BOLT, FLANGE, 10X55 | 1 | |
