F-14 - FLOOR STEP/UNDER COVER
HONDA GRAZIA SCV125SL · 16 parts
Parts in This Assembly (16)
| Ref # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 50621-K1J-D00ZA | COVER, UNDER *NH1* BLACK | 1 | |
| 2 | 64311-K1J-D00ZA | STEP, R. FLOOR *NH1* BLACK | 1 | |
| 3 | 64312-K1J-D00ZA | STEP, L. FLOOR *NH1* BLACK | 1 | |
| 4 | 64315-K1J-D00 | MAT, FLOOR | 1 | |
| 5 | 64316-K1J-D00 | PLATE, R. FLOOR STEP | 1 | |
| 6 | 64317-K1J-D00 | PLATE, L. FLOOR STEP | 1 | |
| 7 | 64320-K1J-D00ZF | COVER SET, R. FLOOR SIDE(WL) *TYPE4* | 1 | |
| 7 | 64320-K1J-D00ZP | COVER SET, R. FLOOR SIDE(WL) *TYPE5 1* | 1 | |
| 7 | 64320-K1J-D00ZS | COVER SET, R. FLOOR SIDE(WL) *TYPE1 1* | 1 | |
| 7 | 64320-K1J-D00ZT | COVER SET, R. FLOOR SIDE(WL) *TYPE8 2* | 1 | |
| 8 | 64330-K1J-D00ZB | COVER SET, L. FLOOR SIDE(WL) *TYPE8* | 1 | |
| 8 | 64330-K1J-D00ZF | COVER SET, L. FLOOR SIDE(WL) *TYPE4* | 1 | |
| 8 | 64330-K1J-D00ZP | COVER SET, L. FLOOR SIDE(WL) *TYPE5 1* | 1 | |
| 8 | 64330-K1J-D00ZS | COVER SET, L. FLOOR SIDE(WL) *TYPE1 1* | 1 | |
| 13 | 90666-K59-A11 | CLIP, SNAP FITTING(PO) | 4 | |
| 15 | 93903-34380 | SCREW, TAPPING, 4X12 | 11 | |
