OEM Part
OEM Part
81255-KZK-900
COVER, CARBURETOR MAINTENANCE
Qty Required: 1
Ref #11 in Assembly
Part of Assembly
F-24
SEAT/LUGGAGE BOX
15 parts in this assembly
Assembly Diagram
Ref #11
Supported Vehicles15
Related Parts
77115-K24-900
RUBBER, SEAL
77200-K86-D01
SEAT COMP., DOUBLE
77201-K24-900
HINGE, SEAT
77206-KG8-900
RUBBER, SEAT SETTING
77215-K24-900
PIN, SEAT HINGE
77234-K86-D00
SPRING, SEAT LOCK
