F-11-FRONT FENDER
HONDAGRAZIA SCV125SK · 18 parts
Parts in This Assembly (18)
| Ref # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 33740-KZK-951 | REFLECTOR, FR. SIDE REFLEX | 2 | |
| 2 | 61000-K86-D00ZA | FENDER SET A, FR.(WL) *TYPE6* | 1 | |
| 2 | 61000-K86-D00ZB | FENDER SET A, FR.(WL) *TYPE5* | 1 | |
| 2 | 61000-K86-D00ZC | FENDER SET A, FR.(WL) *TYPE4* | 1 | |
| 2 | 61000-K86-D00ZD | FENDER SET A, FR.(WL) *TYPE3* | 1 | |
| 2 | 61000-K86-D00ZE | FENDER SET A, FR.(WL) *TYPE2* | 1 | |
| 2 | 61000-K86-D00ZF | FENDER SET A, FR.(WL) *TYPE1* | 1 | |
| 3 | 61103-KRY-900 | COLLAR, A FR.FENDER | 3 | |
| 5 | 61300-K86-D00 | STAY COMP., FR. FENDER | 1 | |
| 6 | 90111-KPL-900 | BOLT, INNER COVER | 1 | |
| 7 | 90113-KVT-901 | BOLT, SPECIAL HEX., 6X20 | 2 | |
| 8 | 90301-KWN-901 | NUT, U, 5MM(FUJI SEIMITSU)..... | 2 | |
| 9 | 90344-KTE-910 | NUT, CLIP, 4MM | 2 | |
| 10 | 90501-K86-D00 | COLLAR, 9.5X6.0 | 2 | |
| 11 | 93903-34480 | SCREW, TAPPING, 4X 16 | 2 | |
| 12 | 94103-05800 | WASHER,PLAIN, 5.5MM | 2 | |
| 13 | 95701-06012-08 | BOLT, FLANGE, 6X12 | 2 | |
| 14 | 95701-06020-08 | BOLT, FLANGE, 6X20 | 1 |
