F-40-1 - BATTERY(SCV125N)
HONDA Activa125 SCV125N · 7 parts
Parts in This Assembly (7)
| Ref # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 31500-KRP-N41 | BATTERY ASSY MF 5 | 1 | |
| 1 | 31500-K0L-D11 | BATTERY(YTZ6V)(GS YUASA) | 1 | |
| 1 | 31500-K0V-A01 | BATTERY ASSY.(ETZ6)(EXIDE) | 1 | |
| 1 | 31500-K0V-B01 | BATTERY ASSY.(ATZ6L) (AMARA RAJA) | 1 | |
| 2 | 50341-K0Y-D00 | BAND COMP., BATTERY | 1 | |
| 3 | 50342-K0P-D00 | CUSHION, BATTERY | 1 | |
| 4 | 93894-05012-08 | SCREW-WASHER, 5X12 | 1 | |
