HONDA OEM Part

42650-K24-G20ZA

WHEEL SUB ASSY., RR. *NH35M* CLOUD SILVER METALLIC

Qty Required: 1 Ref #2 in Assembly

Part of Assembly

F-22-30
REAR WHEEL(SCV125-2ID,3ID)
13 parts in this assembly

Assembly Diagram

F-22-30 REAR WHEEL(SCV125-2ID,3ID) diagram showing 42650-K24-G20ZA
Ref #2

Supported Vehicles2

HHONDA Activa125 SCV125K
HONDA Activa125 SCV125K
Current
HHONDA Activa125 SCV125H
HONDA Activa125 SCV125H

Related Parts

06430-KTN-700
SHOE SET, BRAKE(JB)
06430-KVT-D10
SHOE SET, BRAKE(ASK)
42711-KZK-903
TIRE(TVS)(90/100-10 53J)......
42711-KZK-904
TIRE(MRF)(90/100-10 53J)......
43141-KVT-D10
CAM, RR. BRAKE
43410-KWP-G00
ARM, RR. BRAKE
View all 13 parts in this assembly
