F-9 - STEERING HANDLE/HANDLE COVER
HONDA Activa i SCV110HH · 15 parts
Parts in This Assembly (15)
| Ref # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 53100-K32-900 | HANDLE COMP., STEERING | 1 | |
| 2 | 53124-KWP-900 | COLLAR HANDLE SET | 1 | |
| 3 | 53205-K32-900ZA | COVER, FR. HANDLE | 1 | |
| 3 | 53205-K32-900ZB | COVER, FR. HANDLE *RP193M* AUTUMN BEIGE METALLIC | 1 | |
| 3 | 53205-K32-900ZC | COVER, FR. HANDLE *P104M* EXOTIC PURPLE METALLIC | 1 | |
| 3 | 53205-K32-900ZD | COVER, FR. HANDLE *NHA66P* PEARL SUNBEAM WHITE | 1 | |
| 4 | 86150-KWS-601 | EMBLEM, PRODUCT(SJS) | 1 | |
| 5 | 90304-KTE-911 | NUT, FLANGE SPECIAL, 10MM (SIMMONDS MARSHALL) | 1 | |
| 6 | 90344-KTE-910 | NUT, CLIP, 4MM | 2 | |
| 7 | 90502-KWP-900 | COLLAR B HNDL SET | 1 | |
| 8 | 93891-05016-07 | SCREW WASH 5X16 | 1 | |
| 9 | 93903-34480 | SCREW, TAPPING, 4X 16 | 8 | |
| 10 | 95801-10055-08 | BOLT, FLANGE, 10X55 | 1 | |
| 10 | 95802-10055-08 | BOLT, FLANGE, 10X55 | 1 | |
| 11 | 53250-K32-900 | COVER COMP., RR. HANDLE | 1 | |
