F-14 - FLOOR STEP
HONDA Activa i SCV110HH · 13 parts
Parts in This Assembly (13)
| Ref # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 50621-K32-900 | COVER, UNDER | 1 | |
| 2 | 64310-K32-900 | STEP, FLOOR | 1 | |
| 3 | 64320-K32-900ZA | COVER, R. FLOOR SIDE *R316M* ALPHA RED METALLIC | 1 | |
| 3 | 64320-K32-900ZB | COVER, R. FLOOR SIDE *RP193M* AUTUMN BEIGE METALLIC | 1 | |
| 3 | 64320-K32-900ZC | COVER, R. FLOOR SIDE *P104M* EXOTIC PURPLE METALLIC | 1 | |
| 3 | 64320-K32-900ZD | COVER, R. FLOOR SIDE *NHA66P* PEARL SUNBEAM WHITE | 1 | |
| 4 | 64330-K32-900ZA | COVER, L. FLOOR SIDE *R316M* ALPHA RED METALLIC | 1 | |
| 4 | 64330-K32-900ZB | COVER, L. FLOOR SIDE *RP193M* AUTUMN BEIGE METALLIC | 1 | |
| 4 | 64330-K32-900ZC | COVER, L. FLOOR SIDE *P104M* EXOTIC PURPLE METALLIC | 1 | |
| 4 | 64330-K32-900ZD | COVER, L. FLOOR SIDE *NHA66P* PEARL SUNBEAM WHITE | 1 | |
| 5 | 90344-KRP-900 | NUT CLIP 5MM | 4 | |
| 8 | 93404-06016-07 | BOLT-WASHER, 6 X 16 | 4 | |
| 9 | 93404-06025-07 | BOLT-WASHER, 6X25 | 4 | |
