F-1 - HEADLIGHT
HONDA Activa i SCV110HH · 8 parts
Parts in This Assembly (8)
| Ref # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 33112-K32-901 | COVER, RUBBER | 1 | |
| 2 | 33120-K32-901 | HEADLIGHT UNIT | 1 | |
| 3 | 33706-KWS-901 | TUBE | 2 | |
| 4 | 34901-KSP-910 | BULB, HEAD LIGHT | 1 | |
| 4 | 34901-KVN-971 | BULB HEAD LIGHT | 1 | |
| 5 | 53209-GAH-000 | CLIP, HEADLIGHT | 2 | |
| 6 | 90103-KVH-900 | BOLT, ADJUST | 1 | |
| 7 | 90307-GW3-980 | WASHER, LOCK, 6MM | 1 | |
