F-24 - TOOL
HONDA Activa SCV1109 · 12 parts
Parts in This Assembly (12)
| Ref # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 84510-KPL-900 | AID KIT, FIRST | 1 | |
| 2 | 89010-KPL-900 | TOOL SET(###) | 1 | |
| 3 | 89102-KPL-900 | DRIVER, SCREW(NO.2 +/-) | 1 | |
| 4 | 89103-KPL-900 | GRIP | 1 | |
| 5 | 89215-KPL-900 | HANDLE, EYE WRENCH, 12MM | 1 | |
| 6 | 89216-KPL-900 | WRENCH, PLUG(16) | 1 | |
| 7 | 89217-KPL-900 | WRENCH, BOX(14MM) | 1 | |
| 8 | 89218-KPL-900 | WRENCH, EYE, 19MM | 1 | |
| 9 | 89219-KPL-900 | HANDLE, BOX WRENCH | 1 | |
| 10 | 89225-KPL-900 | SPANNER 10X12 | 1 | |
| 11 | 99008-01600 | BAG, TOOL, 160MM | 1 | |
| 12 | 89214-KPL-900 | WRENCH, EYE, 14MM | 1 | |
