F-21-1 - BATTERY(SCV1109)
HONDA Activa SCV1109 · 8 parts
Parts in This Assembly (8)
| Ref # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 31500-KRP-901 | BATTERY(12MX5L-B) | 1 | |
| 1 | 31500-KRP-902 | BATTERY(AB5L-B) | 1 | |
| 2 | 31502-KWP-900 | TUBE, BATTERY BREATHER | 1 | |
| 3 | 50325-KWP-900 | BOX, BATTERY UPPER | 1 | |
| 4 | 50326-KWP-900 | BOX, BATTERY LOWER | 1 | |
| 5 | 50341-KVT-900 | BAND COMP., BATTERY | 1 | |
| 6 | 95003-12046-10 | V.TUBE 5X7X460 | 1 | |
| 7 | 95701-06012-08 | BOLT, FLANGE, 6X12 | 1 | |
