F-29 - BATTERY
HONDA CBR650F CBR650FAG · 8 parts
Parts in This Assembly (8)
| Ref # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 31500-MGZ-T11 | BATTERY(FTZ10S)(FURUKAWA) | 1 | |
| 2 | 32410-MJE-D00 | CABLE, STARTER MOTOR | 1 | |
| 3 | 32601-MJE-D00 | CABLE, BATTERY EARTH | 1 | |
| 4 | 35850-MT4-003 | SWITCH ASSY., STARTER MAGNETIC | 1 | |
| 5 | 35856-MBG-003 | RUBBER, SHOCK | 1 | |
| 6 | 90111-MR5-000 | BOLT, SOCKET, 5X9 | 2 | |
| 7 | 95012-17001 | BAND F, BATTERY(155MM) | 1 | |
| 8 | 98200-33000 | FUSE, BLADE(30A) | 2 | |
