OEM Part
OEM Part
06435-KYJ-711
PAD SET, RR.
Qty Required: 1
Ref #2 in Assembly
Part of Assembly
F-17
REAR BRAKE CALIPER(CBR250R)
15 parts in this assembly
Assembly Diagram
Ref #2
Supported Vehicles6
Related Parts
06431-MAK-003
SEAL SET, PISTON
06436-KYJ-711
PIN SET, HANGER
43107-KYJ-711
PISTON
43108-KYJ-711
SPRING, PAD
43110-KYJ-711
BRACKET, RR.
43111-KYJ-711
RETAINER
