F-17 - REAR BRAKE CALIPER
HONDA CB300R CBF300NAK · 12 parts
Parts in This Assembly (12)
| Ref # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 06435-KSP-B02 | PAD SET, RR | 1 | |
| 2 | 06451-961-405 | SEAL SET, PISTON | 1 | |
| 3 | 43108-KSP-B51 | SPRING, PAD(NISSIN) | 1 | |
| 4 | 43112-KZZ-901 | RETAINER | 1 | |
| 5 | 43150-K94-T11 | CALIPER SUB ASSY., RR.(NISSIN) | 1 | |
| 6 | 43190-K94-T11 | BRACKET SUB ASSY., RR. | 1 | |
| 7 | 43215-KGH-901 | PIN,HANGER | 1 | |
| 10 | 45107-MA6-006 | PISTON | 1 | |
| 11 | 45111-MAJ-G41 | STOPPER RING | 1 | |
| 12 | 45132-166-016 | BOOT, PIN BUSH(NISSIN) | 1 | |
| 13 | 45133-MA3-006 | BOOT B | 1 | |
| 14 | 45203-MCC-006 | PLUG,PIN | 1 | |
