F-12-2 - REAR WHEEL(CAST/DISK BRAKE)
HONDA CB Unicorn Dazzler CBF150MC · 22 parts
Parts in This Assembly (22)
| Ref # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 06410-KSP-900 | DAMPER SET, WHEEL | 1 | |
| 2 | 41200-KSP-B00 | SPROCKET COMP., FINAL DRIVEN(42T) | 1 | |
| 3 | 42301-KSP-B00 | AXLE, RR. WHEEL | 1 | |
| 4 | 42303-KSP-B00 | SLEEVE, RR. WHEEL | 1 | |
| 5 | 42304-KSP-B00 | COLLAR, RR. WHEEL SIDE | 1 | |
| 6 | 42313-KSP-B00 | COLLAR, RR. BRAKE SIDE | 1 | |
| 7 | 42615-KSP-B00ZA | FLANGE SUB ASSY., FINAL DRIVEN *NH303M* MAT AXIS GRAY METALLIC | 1 | |
| 8 | 42620-KSP-B00 | COLLAR, RR. AXLE DISTANCE | 1 | |
| 9 | 42650-KSP-B01ZA | WHEEL SUB ASSY., RR. *NH303M* MAT AXIS GRAY METALLIC | 1 | |
| 10 | 42711-KSP-B01 | TIRE, RR.(MRF)(110/80-17 57P) | 1 | |
| 12 | 43251-KSP-B01ZA | DISK, RR. BRAKE(YUTAKA) *TYPEA* | 1 | |
| 14 | 90304-KST-942 | NUT FLG.PT 10MM | 4 | |
| 14 | 90304-KTE-911 | NUT, FLANGE SPECIAL, 10MM (SIMMONDS MARSHALL) | 4 | |
| 15 | 90305-KVN-901 | NUT, FLANGE, 14MM (SIMMONDS MARSHALL) | 1 | |
| 15 | 90305-KVN-902 | NUT, FLANGE, 14MM(LEO FASTENERS) | 1 | |
| 16 | 90560-KSP-B00 | WASHER, RR. AXLE | 2 | |
| 17 | 91257-230-003 | OIL SEAL 28X42X7 | 2 | |
| 17 | 91257-230-005 | OIL SEAL, 28X42X7(NOK) | 2 | |
| 18 | 91352-KSP-900 | O RING, 51 X 2 | 1 | |
| 19 | 92915-10025-0E | BOLT, STUD II, 10X25 | 4 | |
| 20 | 96150-60040-10 | BEARING, RADIAL BALL, 6004UU | 1 | |
| 21 | 96150-63020-10 | BEARING BALL RADIAL, 6302(UU) | 2 | |
