F-10 - FRONT WHEEL(SPOKE)
HONDA CB Unicorn CBF1505 · 22 parts
Parts in This Assembly (22)
| Ref # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 06440-KFN-850 | SPOKE SET A, FR.(OUTSIDE) | 18 | |
| 2 | 06441-KFN-850 | SPOKE SET B, FR.(INSIDE) | 18 | |
| 3 | 42713-KSP-901 | FLAP, TIRE(1.60/1.85-18) | 1 | |
| 4 | 44301-KSP-900 | AXLE, FRONT WHEEL | 1 | |
| 5 | 44311-KSP-900 | COLLAR, FR. WHEEL SIDE | 1 | |
| 6 | 44620-KSP-900 | COLLAR FR AXLE DIST | 1 | |
| 7 | 44635-KSP-900ZA | HUB SUB ASSY., FR. *NH35M* CLOUD SILVER METALLIC | 1 | |
| 8 | 44650-KSP-900ZA | WHEEL SUB ASSY., FR. *NH35M* CLOUD SILVER METALLIC | 1 | |
| 9 | 44680-410-000 | RETAINER, GEAR BOX | 1 | |
| 10 | 44701-KRM-860 | RIM, FR. WHEEL | 1 | |
| 10 | 44701-KSP-900 | RIM, FR. WHEEL | 1 | |
| 11 | 44711-KFN-852 | TIRE, FR.(2.75-18 42P) | 1 | |
| 12 | 44712-KFN-852 | TUBE(2.75-18) | 1 | |
| 13 | 44800-KSP-900ZA | BOX ASSY., SPEEDOMETER GEAR *NH35M* CLOUD SILVER METALLIC | 1 | |
| 14 | 44804-KSP-901 | GEAR, SPEEDOMETER | 1 | |
| 15 | 44809-KPL-900 | WASHER, SPEEDOMETER GEAR | 1 | |
| 16 | 45251-KSP-901 | DISK, FR. BRAKE | 1 | |
| 17 | 90105-KSP-900 | BOLT, BRAKE DISK, 6X18 | 5 | |
| 18 | 90306-KGH-901 | NUT, U, 12MM(FUJI SEIMITSU) | 1 | |
| 19 | 91251-KPH-901 | DUST SEAL, 21 X 37 X 7 | 1 | |
| 20 | 91258-410-013 | DUST SEAL, 40X50X5(ARAI) | 1 | |
| 21 | 96140-63010-10 | BEARING, RADIAL BALL, 6301U | 2 | |
