F-27 - EXHAUST MUFFLER
HONDA CB125 Hornet CBF125ZT · 17 parts
Parts in This Assembly (17)
| Ref # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 18291-GE2-921 | GASKET, EX. PIPE | 1 | |
| 2 | 18293-MCA-A20 | RUBBER, PROTECTOR PACKING | 1 | |
| 3 | 18300-K4F-D00 | MUFFLER COMP., EX. | 1 | |
| 4 | 18345-K15-920 | RUBBER, MOUNTING | 2 | |
| 5 | 18345-MBT-610 | RUBBER, PROTECTOR, MOUNT | 2 | |
| 6 | 18355-K4F-D00 | COVER, MUFFLER | 1 | |
| 7 | 18357-K4F-D00 | CAP, MUFFLER TAIL | 1 | |
| 8 | 18421-438-670 | RUBBER, MUFFLER MOUNT | 1 | |
| 9 | 18442-KRC-900 | COLLAR, MUFFLER MOUNT | 1 | |
| 10 | 36531-K0N-DU1 | SENSOR, OXYGEN(ZFAS-S5.1) | 1 | |
| 11 | 90113-KYJ-710 | SCREW, PAN, 6X12 | 2 | |
| 12 | 90130-K1P-D00 | SCREW, PAN, 6X15 | 2 | |
| 13 | 90304-K0V-AC0 | NUT, FLANGE, 7MM | 2 | |
| 14 | 90501-K4F-D00 | COLLAR | 2 | |
| 15 | 94050-10080 | NUT, FLANGE, 10MM | 1 | |
| 16 | 94103-10000 | WASHER, PLAIN, 10MM | 1 | |
| 17 | 95801-10055-08 | BOLT, FLANGE, 10X55 | 1 | |
