F-23-10 - REAR COWL
HONDA CB Shine/ Shine 125 CBF125S · 23 parts
Parts in This Assembly (23)
| Ref # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 77209-KTE-650 | CUSHION, RR. COWL | 2 | |
| 2 | 77260-K0V-A00ZA | COWL SET, R. RR.(WL) *TYPE7* | 1 | |
| 2 | 77260-K0V-A00ZB | COWL SET, R. RR.(WL) *TYPE6* | 1 | |
| 2 | 77260-K0V-A00ZC | COWL SET, R. RR.(WL) *TYPE5* | 1 | |
| 2 | 77260-K0V-A00ZD | COWL SET, R. RR.(WL) *TYPE4* | 1 | |
| 2 | 77260-K0V-A00ZE | COWL SET, R. RR.(WL) *TYPE3* | 1 | |
| 2 | 77260-K0V-A00ZF | COWL SET, R. RR.(WL) *TYPE2* | 1 | |
| 2 | 77260-K0V-A00ZG | COWL SET, R. RR.(WL) *TYPE1* | 1 | |
| 3 | 77270-K0V-A00ZA | COWL SET, L. RR.(WL) *TYPE7* | 1 | |
| 3 | 77270-K0V-A00ZB | COWL SET, L. RR.(WL) *TYPE6* | 1 | |
| 3 | 77270-K0V-A00ZC | COWL SET, L. RR.(WL) *TYPE5* | 1 | |
| 3 | 77270-K0V-A00ZD | COWL SET, L. RR.(WL) *TYPE4* | 1 | |
| 3 | 77270-K0V-A00ZE | COWL SET, L. RR.(WL) *TYPE3* | 1 | |
| 3 | 77270-K0V-A00ZF | COWL SET, L. RR.(WL) *TYPE2* | 1 | |
| 3 | 77270-K0V-A00ZG | COWL SET, L. RR.(WL) *TYPE1* | 1 | |
| 4 | 77280-K0V-A00ZB | COWL SET, RR. CENTER(WL) *TYPE7* | 1 | |
| 4 | 77280-K0V-A00ZC | COWL SET, RR. CENTER(WL) *TYPE6* | 1 | |
| 4 | 77280-K0V-A00ZD | COWL SET, RR. CENTER(WL) *TYPE5* | 1 | |
| 4 | 77280-K0V-A00ZE | COWL SET, RR. CENTER(WL) *TYPE4* | 1 | |
| 4 | 77280-K0V-A00ZF | COWL SET, RR. CENTER(WL) *TYPE3* | 1 | |
| 4 | 77280-K0V-A00ZG | COWL SET, RR. CENTER(WL) *TYPE2* | 1 | |
| 4 | 77280-K0V-A00ZH | COWL SET, RR. CENTER(WL) *TYPE1* | 1 | |
| 5 | 93903-24380 | SCREW TAPPING, 4 X 12 | 4 | |
