F-31 - FRONT COWL
HONDA CB Shine/ Shine 125 CBF125MCC · 20 parts
Parts in This Assembly (20)
| Ref # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 33740-KTE-601 | REFLECTOR, FR. SIDE REFLEX | 2 | |
| 2 | 37312-KT2-000 | GROMMET, COMBINATION SWITCH | 1 | |
| 3 | 61103-357-000 | RUBBER FR. FENDER MOUNT | 4 | |
| 4 | 61104-KTE-600 | STAY, REFLECTOR | 1 | |
| 5 | 61300-KTE-600ZA | VISOR SET, FR.(WL) *TYPE5* | 1 | |
| 5 | 61300-KTE-600ZB | VISOR SET, FR.(WL) *TYPE4* | 1 | |
| 5 | 61300-KTE-600ZC | VISOR SET, FR.(WL) *TYPE3* | 1 | |
| 5 | 61300-KTE-600ZD | VISOR SET, FR.(WL) *TYPE2* | 1 | |
| 5 | 61300-KTE-600ZE | VISOR SET, FR.(WL) *TYPE1* | 1 | |
| 6 | 61310-KTE-600 | COVER COMP., HEADLIGHT RR. | 1 | |
| 7 | 61313-KTE-600 | GROMMET, VISOR | 1 | |
| 8 | 64315-KTE-600 | STAY, FR. NUMBER PLATE | 1 | |
| 9 | 90302-KTE-911 | NUT FLANGE PT 6MM | 2 | |
| 10 | 90310-KWS-900 | COLLAR, FR. COWL | 4 | |
| 11 | 90320-GC3-000 | NUT, SPRING, M5 | 5 | |
| 12 | 90320-KTE-600 | NUT, SPRING, 5MM | 2 | |
| 13 | 91509-GE2-760 | SCREW, WASHER, 5 X 11.5 | 5 | |
| 14 | 92101-05012-0A | BOLT, HEX., 5X12 | 2 | |
| 15 | 93903-25220 | SCREW, TAPPING, 5X12 | 2 | |
| 16 | 94101-05000 | WASHER , PLAIN, 5MM | 2 | |
