F-15 - SEAT
HONDA CB Shine/ Shine 125 CBF125MCC · 18 parts
Parts in This Assembly (18)
| Ref # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 16574-ZG8-300 | SPRING, LEVER | 1 | |
| 2 | 50400-KTE-950ZB | GRIP, RR. *NHA04M* GENY GRAY METALLIC | 1 | |
| 2 | 50400-KTE-950ZC | GRIP, RR. *NH1* BLACK | 1 | |
| 2 | 50400-KTE-950ZE | GRIP, RR. *R329M* REBEL RED METALLIC | 1 | |
| 2 | 50400-KTE-950ZF | GRIP, RR. *NH411M* FORCE SILVER METALLIC | 1 | |
| 2 | 50400-KTE-950ZG | GRIP, RR. *NHB04M* MONSOON GRAY METALLIC | 1 | |
| 3 | 75581-GN8-920 | SET SPG LOCK KEY | 1 | |
| 4 | 77106-KTE-950 | STAY, HELMET HOLDER | 1 | |
| 5 | 77156-KTE-910 | CABLE, SEAT LOCK | 1 | |
| 6 | 77200-KTE-600ZA | SEAT ASSY., DOUBLE *TYPE1* | 1 | |
| 6 | 77200-KTE-A00 | SEAT ASSY., DOUBLE *TYPE1* | 1 | |
| 7 | 77204-KCC-900 | RUBBER, `A SEAT SETTING | 2 | |
| 8 | 77206-KTE-910 | RUBBER, SEAT SETTING | 4 | |
| 9 | 77225-KTE-911 | LOCK ASSY., SEAT | 1 | |
| 10 | 77235-KTE-910 | CATCH COMP., SEAT | 1 | |
| 11 | 77251-KPL-900 | BAG, SERVICE BOOK | 1 | |
| 13 | 95701-08020-00 | BOLT, FLANGE, 8X20 | 4 | |
| 13 | 95702-08020-00 | BOLT, FLANGE, 8X20 | 4 | |
