F-16-1 - REAR COWL(2)
HONDA CBF Stunner CBF125MC · 19 parts
Parts in This Assembly (19)
| Ref # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 19052-KV0-000 | COLLAR, RADIATOR MTG | 2 | |
| 2 | 77210-KWF-900ZF | COWL, RR. LOWER *NH1* BLACK | 1 | |
| 2 | 77210-KWF-900ZK | COWL, RR. LOWER *NH194MU* HEAVY GRAY METALLIC-U | 1 | |
| 3 | 77230-KWF-900ZD | COWL, RR. UPPER *NHB06M* SPACE SILVER METALLIC | 1 | |
| 3 | 77230-KWF-900ZC | COWL, RR. UPPER *R321* SPORTS RED | 1 | |
| 3 | 77230-KWF-900ZG | COWL, RR. UPPER *Y206P* PEARL SPORTS YELLOW | 1 | |
| 3 | 77230-KWF-900ZF | COWL, RR. UPPER *R101CU* CANDY GLORY RED-U | 1 | |
| 3 | 77230-KWF-900ZA | COWL, RR. UPPER *NH1* BLACK | 1 | |
| 4 | 77240-KWF-900ZB | LID TAIL LIGHT(BLACK,NH-1) | 1 | |
| 4 | 77240-KWF-900ZF | LID, TAILLIGHT *Y206P* PEARL SPORTS YELLOW | 1 | |
| 4 | 77240-KWF-900ZC | LID TAIL LIGHT(PEAR FADELESS WHITE,NH-341P) | 1 | |
| 4 | 77240-KWF-900ZE | LID, TAILLIGHT *R101CU* CANDY GLORY RED-U | 1 | |
| 4 | 77240-KWF-900ZA | LID TAIL LIGHT(SPORTS RED,R-321) | 1 | |
| 5 | 83502-KCC-900 | GROMMET, SIDE COVER | 2 | |
| 6 | 83545-KCJ-690 | RUBBER, SIDE COVER | 2 | |
| 7 | 83551-GE2-000 | GROMMET, AIR CLENER CASE | 2 | |
| 9 | 93903-24480 | SCREW, TAPPING, 4X16 | 2 | |
| 10 | 93913-14280 | SCREW TAPPING 4X12 | 5 | |
| 11 | 96001-06020 | BOLT, FLANGE, 6X20 | 2 | |
