OEM Part
OEM Part
40530-KWF-902
CHAIN, DRIVE(LGB R420BS-118L)
Qty Required: 1
Ref #3 in Assembly
Part of Assembly
F-23-1
SWINGARM(2)
18 parts in this assembly
Assembly Diagram
Ref #3
Supported Vehicles2
Related Parts
40510-KWF-900ZA
CASE, UPPER HALF DRIVE CHAIN *NH303M* MAT AXIS GRAY METALLIC
40520-KWF-900ZA
CASE, UNDER HALF DRIVE CHAIN *NH303M* MAT AXIS GRAY METALLIC
40530-KWF-901
CHAIN, DRIVE(RK420SBZ1-118RJ)
40531-KST-944
JOINT RJ DRIVE CHAIN
40531-KTE-912
JOINT, DRIVE CHAIN(LGB)
40543-KWF-900
ADJUSTER COMP L CHAIN
