F-2-1 - METER(2)
HONDA CBF Stunner CBF125M9/MF · 27 parts
Parts in This Assembly (27)
| Ref # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 34908-KVE-900 | BULB, WEDGE BASE T10 (12V - 1.7 W) | 5 | |
| 2 | 37100-KWF-902 | METER ASSY., COMBINATION | 1 | |
| 2 | 37100-KWF-932 | METER ASSY., COMBINATION | 1 | |
| 2 | 37100-KWF-961 | METER ASSY., COMBINATION | 1 | |
| 3 | 37200-KWF-901 | SPEEDOMETER ASSY.(KPH) | 1 | |
| 3 | 37200-KWF-951 | SPEEDOMETER ASSY.(KPH) | 1 | |
| 4 | 37215-KS3-901 | CLAMP | 1 | |
| 5 | 37220-KWF-901 | KNOB | 1 | |
| 6 | 37300-KWF-901 | METER COMP., FUEL | 1 | |
| 6 | 37300-KWF-961 | METER COMP., FUEL | 1 | |
| 7 | 37305-KE5-008 | SCREW-WASHER, 3X22 | 3 | |
| 8 | 37305-MAW-621 | SCREW, WASH SPL., 4X12 | 2 | |
| 9 | 37610-KWF-901 | CASE ASSY., UPPER | 1 | |
| 9 | 37610-KWF-931 | CASE ASSY., UPPER | 1 | |
| 10 | 37612-KWF-901 | CASE ASSY., UNDER | 1 | |
| 10 | 37612-KWF-951 | CASE ASSY., UNDER | 1 | |
| 11 | 37619-KWF-902 | SOCKET COMP. | 1 | |
| 12 | 44830-KWF-900 | CABLE COMP., SPEEDOMETER | 1 | |
| 13 | 80101-443-000 | RUBBER, RR. FENDER CUSHION | 4 | |
| 14 | 90109-MZ5-008 | SCREW, TAPPING, 4 X 14 | 1 | |
| 15 | 90158-KM7-911 | SCREW,TRIP KNOB,2X6 | 1 | |
| 16 | 91352-671-003 | O-RING, 8.5X1.5(ARAI) | 1 | |
| 16 | 91352-671-004 | O-RING, 8.5X1.5(NOK) | 1 | |
| 17 | 93903-22420 | SCREW,TAPPING,3 X 16 | 6 | |
| 18 | 94001-06070-0S | NUT, HEX., 6 MM | 4 | |
| 19 | 94103-06700 | WASHER, PLAIN, 6 MM | 4 | |
| 20 | 37619-KWF-961 | SOCKET COMP. | 1 | |
