F-15-1 - SEAT(2)
HONDA CBF Stunner CBF125M9/MF · 21 parts
Parts in This Assembly (21)
| Ref # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 50400-KWF-900ZG | GRIP, RR. *R321* SPORTS RED | 1 | |
| 1 | 50400-KWF-900ZH | GRIP, RR. *NHB06M* SPACE SILVER METALLIC | 1 | |
| 1 | 50400-KWF-900ZK | GRIP, RR. *R101CU* CANDY GLORY RED-U | 1 | |
| 1 | 50400-KWF-900ZL | GRIP, RR. *Y206P* PEARL SPORTS YELLOW | 1 | |
| 1 | 50400-KWF-900ZF | GRIP, RR. *NH1* BLACK | 1 | |
| 1 | 50400-KWF-900ZJ | GRIP, RR. *Y163P* PEARL FLASH YELLOW | 1 | |
| 2 | 64122-KV0-000 | RUB B , SIDESHELTER | 2 | |
| 3 | 75581-GN8-920 | SET SPG LOCK KEY | 1 | |
| 4 | 77100-KWF-900 | SEAT COMP., SINGLE | 1 | |
| 5 | 77204-KCC-900 | RUBBER, `A SEAT SETTING | 4 | |
| 6 | 77205-286-000 | RUBBER `B SEAT SETTING | 2 | |
| 7 | 77206-KFN-850 | RUBBER SEAT CUSHION | 2 | |
| 8 | 77207-KWF-900 | COLLAR , SEAT MOUNTING | 2 | |
| 9 | 77225-KWF-901 | LOCK ASSY., SEAT | 1 | |
| 10 | 77235-KWF-900 | SEAT CATCH COMP | 1 | |
| 11 | 77236-GBL-000 | SPRING SEAT CATCH | 1 | |
| 12 | 77251-KPL-900 | BAG, SERVICE BOOK | 1 | |
| 13 | 77300-KWF-900 | SEAT COMP., PILLION | 1 | |
| 14 | 81202-KWF-900 | COLLAR, CARRIER | 4 | |
| 15 | 95701-06025-08 | BOLT, FLANGE, 6X25 | 2 | |
| 16 | 95701-08025-00 | BOLT, FLANGE 8 X 25 | 4 | |
