F-28 - BATTERY
HONDA CB Shine/ Shine 125 CBF125L · 20 parts
Parts in This Assembly (20)
| Ref # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 31500-KVT-941 | BATTERY ASSY.,MF4 | 1 | |
| 1 | 31500-KTE-621 | BATTERY(ATZ4L)(AMARA RAJA) | 1 | |
| 2 | 32401-KTE-650 | CABLE, STARTER MAGNETIC BATTERY | 1 | |
| 3 | 32406-KTE-650 | COVER, STARTER MAGNETIC TERMINAL | 1 | |
| 4 | 32410-KTE-650 | CABLE, STARTER MOTOR | 1 | |
| 5 | 32411-253-000 | COVER, STARTING MOTOR | 1 | |
| 6 | 32417-KTE-650 | COVER, BATTERY TERMINAL | 1 | |
| 7 | 32601-KTE-650 | CABLE, BATTERY EARTH | 1 | |
| 8 | 35850-K38-901 | SWITCH ASSY., STARTER MAGNETIC | 1 | |
| 8 | 35850-K67-901 | SWITCH ASSY., STARTER MAGNETIC (MINDA) | 1 | |
| 9 | 35856-KTE-650 | RUBBER, SHOCK | 1 | |
| 10 | 50380-KTE-D00 | BOX, BATTERY | 1 | |
| 11 | 50381-KTE-650 | BAND, BATTERY | 1 | |
| 12 | 77211-KVE-900 | CUSHION RR. COWL | 1 | |
| 13 | 90111-MR5-000 | BOLT, SOCKET, 5X9 | 2 | |
| 14 | 90116-KVB-900 | BOLT, FLANGE, 6MM | 2 | |
| 16 | 92301-06012-0A | BOLT RECESSED 6X12 | 1 | |
| 17 | 95002-40850-08 | CLAMP, TUBE(D8.5) | 1 | |
| 18 | 95005-50380-30 | TUBE, 5X380(95005-50001-30M) | 1 | |
| 19 | 98200-32000 | BLADE, FUSE, 20A | 2 | |
