F-36 - TAILLIGHT(CB350D/DS)
HONDA HNESS CB350DS · 3 parts
Parts in This Assembly (3)
| Ref # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 33701-K0Z-DH1 | TAILLIGHT UNIT | 1 | |
| 2 | 33720-K0Z-D01 | LIGHT ASSY., LICENSE | 1 | |
| 3 | 91509-K0Z-900 | SCREW, PAN, 5X13.5 | 2 | |
