F-50-1 - EMBLEM
HONDA CB350 CB350CST · 26 parts
Parts in This Assembly (26)
| Ref # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 3 | 86171-K3R-DB0ZA | STRIPE A, R. FUEL TANK *TYPE2* | 1 | |
| 3 | 86171-K3R-DB0ZB | STRIPE A, R. FUEL TANK *TYPE1* | 1 | |
| 4 | 86172-K3R-DB0ZA | STRIPE A, L. FUEL TANK *TYPE2* | 1 | |
| 4 | 86172-K3R-DB0ZB | STRIPE A, L. FUEL TANK *TYPE1* | 1 | |
| 5 | 86173-K3R-DB0ZA | STRIPE B, R. FUEL TANK *TYPE2* | 1 | |
| 5 | 86173-K3R-DB0ZB | STRIPE B, R. FUEL TANK *TYPE1* | 1 | |
| 6 | 86174-K3R-DB0ZA | STRIPE B, L. FUEL TANK *TYPE2* | 1 | |
| 6 | 86174-K3R-DB0ZB | STRIPE B, L. FUEL TANK *TYPE1* | 1 | |
| 7 | 86177-K3R-DB0ZA | STRIPE, SPECIAL EDITION *TYPE2* | 1 | |
| 7 | 86177-K3R-DB0ZB | STRIPE, SPECIAL EDITION *TYPE1* | 1 | |
| 8 | 86611-K3R-DB0ZA | STRIPE A, FR. FENDER *TYPE2* | 1 | |
| 8 | 86611-K3R-DB0ZB | STRIPE A, FR. FENDER *TYPE1* | 1 | |
| 9 | 86612-K3R-DB0ZA | STRIPE B, FR. FENDER *TYPE2* | 1 | |
| 9 | 86612-K3R-DB0ZB | STRIPE B, FR. FENDER *TYPE1* | 1 | |
| 10 | 86811-K3R-DB0ZA | STRIPE, RR. FENDER *TYPE2* | 1 | |
| 10 | 86811-K3R-DB0ZB | STRIPE, RR. FENDER *TYPE1* | 1 | |
| 11 | 86831-K3R-D90ZA | EMBLEM, R. SIDE COVER *TYPE1* | 1 | |
| 12 | 86832-K3R-D90ZA | EMBLEM, L. SIDE COVER *TYPE1* | 1 | |
| 13 | 86833-K3R-DB0ZA | STRIPE A, R. SIDE COVER *TYPE2* | 1 | |
| 13 | 86833-K3R-DB0ZB | STRIPE A, R. SIDE COVER*TYPE1* | 1 | |
| 14 | 86834-K3R-DB0ZA | STRIPE A, L. SIDE COVER *TYPE2* | 1 | |
| 14 | 86834-K3R-DB0ZB | STRIPE A, L. SIDE COVER*TYPE1* | 1 | |
| 15 | 86835-K3R-DB0ZA | STRIPE B, R. SIDE COVER *TYPE2* | 1 | |
| 15 | 86835-K3R-DB0ZB | STRIPE B, R. SIDE COVER*TYPE1* | 1 | |
| 16 | 86836-K3R-DB0ZA | STRIPE B, L. SIDE COVER*TYPE2* | 1 | |
| 16 | 86836-K3R-DB0ZB | STRIPE B, L. SIDE COVER*TYPE1* | 1 | |
