F-36-1 - TAILLIGHT(MINDA)
HONDA CD 110 Dream CB110C2MG · 5 parts
Parts in This Assembly (5)
| Ref # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 33701-K23-902 | TAILLIGHT UNIT(12V 21/5W) | 1 | |
| 2 | 33703-K23-902 | LENS COMP., TAILLIGHT | 1 | |
| 3 | 33704-K23-902 | BASE COMP., TAILLIGHT | 1 | |
| 4 | 33705-K23-902 | PACKING, LENS | 1 | |
| 6 | 33707-K23-902 | PACKING, LENS | 2 | |
