F-37 - BATTERY
HONDA CD 110 Dream CB110C2K · 9 parts
Parts in This Assembly (9)
| Ref # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 17223-KVX-600 | COLLAR, AIR CLEANER | 1 | |
| 2 | 31500-KWS-801 | BATTERY ASSY., MF3-BS | 1 | |
| 2 | 31500-KWS-901 | BATTERY ASSY | 1 | |
| 3 | 50325-K63-D30 | BOX, BATTERY | 1 | |
| 4 | 50326-KZA-W00 | BAND BATTERY | 1 | |
| 5 | 77211-KVE-900 | CUSHION RR. COWL | 1 | |
| 7 | 90311-MT3-000 | NUT, CLIP, 6 MM | 1 | |
| 8 | 93903-25380 | SCREW TAPPING 5X16 | 1 | |
| 9 | 95701-06016-08 | BOLT, FLANGE, 6X16 | 1 | |
