F-3-HANDLE LEVER / SWITCH/ CABLES
HeroXpulse 200FI (May, 2019) · 5 parts
Parts in This Assembly (5)
| Ref # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 22870-ABW-100 | CABLE COMP CLUTCH | 1 | |
| 2 | 22871-KTN-700 | BOOT, CLUTCH CABLE | 1 | |
| 3 | 53182-KFN-850 | BOOT, L HANDLE LEVER | 1 | |
| 4 | 94002-08000-0S | NUT HEX.8 MM | 1 | |
| 5 | 94030-08000 | NUT, HEX., 8 MM | 1 |
