F-11-DISC - REAR WHEEL
Hero MAESTRO EDGE 125CC(March,2023) · 10 parts
Parts in This Assembly (10)
| Ref # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 42601-ABG-20099 | WHEEL COMP REAR | 1 | |
| 2 | 42711-AAL-00099 | TYRE | 1 | |
| 4 | 43141-KTP-900 | CAM, REAR BRAKE | 1 | |
| 5 | 43410-AAW-000 | ARM REAR BRAKE | 1 | |
| 6 | 43472-KPL-900 | SPRING, REAR, BRAKE ARM | 1 | |
| 9 | 95015-42000 | NUT B ADJUST | 1 | |
| 10 | 90112-KTP-900 | BOLT, FLANGE, 6X32 | 1 | |
| 11 | 90305-KPL-900 | NUT, HEX, SPL., 16MM | 1 | |
| 12 | 95015-32001 | JOINT B BRAKE ARM | 1 | |
| 13 | 90501-KPL-900 | WASHER, 16 MM | 1 | |
