F-25-DRUM - FRAME BODY
Hero Glamour FI-iBS BSVI (Jan, 2021) · 18 parts
Parts in This Assembly (18)
| Ref # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 33714-KL3-620 | RUBBER, TAIL LIGHT | 2 | |
| 2 | 38110-AAN-00099 | HORN COMP | 1 | |
| 3 | 38117-KFE-701 | COLLAR, HORN SET | 1 | |
| 4 | 50100-AAN-B00 | FRAME BODY COMP., | 1 | |
| 5 | 50351-AAF-400 | PLATE FRONT ENG HANGER | 1 | |
| 6 | 95701-06016-07 | BOLT, FLANGE, 6 X 16 | 1 | |
| 7 | 94050-10000 | NUT, FLANGE, 10MM | 2 | |
| 8 | 95801-08090-00 | BOLT FLANGE 8X90 | 3 | |
| 9 | 43443-AAC-830 | CLIP CBS CABLE | 2 | |
| 10 | 50157-AAF-400 | CLIP HARNESS | 1 | |
| 11 | 90019-AAG-300 | BOLT FLANGE 10 X 110 | 2 | |
| 12 | 50137-AAR-000 | PLUG CABLE RETENTION | 1 | |
| 13 | 95701-06012-00 | BOLT, FLANGE, 6X12 | 2 | |
| 14 | 95701-06020-00 | BOLT, FLANGE, 6X20 | 1 | |
| 15 | 94050-08000 | NUT, FLANGE, 8MM | 3 | |
| 16 | 95801-08095-00 | BOLT, FLANGE, 8 X 95 | 1 | |
| 17 | 50141-AAN-B10 | GUIDE CONTROL CABLEE | 1 | |
| 18 | 50328-KVN-900 | RUBBER, TANK MTG. | 2 | |
