F-41 - WIRE HARNESS
HONDA Activa i SCV110HK · 24 parts
Parts in This Assembly (24)
| Ref # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 30401-KVE-901 | CUSHION, C.D.I. UNIT | 1 | |
| 2 | 30410-KVT-D01 | C.D.I. UNIT | 1 | |
| 3 | 30500-K32-901 | COIL ASSY., IGNITION | 1 | |
| 4 | 30520-GFM-900 | SPACER, IGNITION COIL | 2 | |
| 5 | 30700-KWP-901 | CAP ASSY NOISE SUPPRESSOR | 1 | |
| 6 | 31600-KWP-D01 | RECTIFIER COMP., REGULATE(STAR ENGINEERS) | 1 | |
| 7 | 32100-K32-900 | HARNESS, WIRE | 1 | |
| 8 | 35012-KZK-D00 | SWITCH ASSY. SET, COMBINATION & LOCK | 1 | |
| 9 | 35014-KZK-D00 | KEY & SCREW SET | 1 | |
| 10 | 35121-KPL-841 | KEY, BLANK | 1 | |
| 11 | 38110-K32-901 | HORN COMP. | 1 | |
| 12 | 38501-KPL-901 | RELAY COMP., STARTER(MULTILINK) | 1 | |
| 13 | 38506-KPL-900 | SUSP . START RELAY | 1 | |
| 14 | 90164-KPL-900 | SCREW, FLAT, U LOCK, 6X12 | 2 | |
| 14 | 90164-KEE-630 | SCREW FLAT 6X12 | 2 | |
| 15 | 92101-06020-4J | BOLT, HEX., 6 X 20 | 2 | |
| 16 | 95701-06012-00 | BOLT, FLANGE, 6X12 | 1 | |
| 16 | 95702-06012-00 | BOLT, FLANGE, 6X12 | 1 | |
| 17 | 95701-06012-08 | BOLT, FLANGE, 6X12 | 1 | |
| 17 | 95702-06012-08 | BOLT, FLANGE, 6X12 | 1 | |
| 18 | 95702-06016-08 | BOLT, FLANGE, 6X16 | 1 | |
| 18 | 95701-06016-08 | BOLT, FLANGE, 6X16 | 1 | |
| 19 | 98200-31000 | BLADE, FUSE 10A | 2 | |
| 20 | 98200-31500 | BLADE, FUSE, 15A | 2 | |
