F-9-10 - FRONT CUSHION
HONDA Activa SCV110E · 14 parts
Parts in This Assembly (14)
| Ref # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 51400-KPL-901 | CUSHION ASSY., R. FR.(SHOWA) | 1 | |
| 1 | 51400-KPL-902 | CUSHION ASSY., R. FR.(GABRIEL) | 1 | |
| 2 | 51413-GC8-003 | BUSH, FR. CUSHION UNDER | 4 | |
| 2 | 51413-KPL-902 | BUSH, FR. CUSHION UNDER(GABRIEL) | 4 | |
| 3 | 51486-GC8-003 | COLLAR, RUBBER, BUSH | 2 | |
| 3 | 51486-KPL-902 | COLLAR, ARM PIVOT(GABRIEL) | 2 | |
| 4 | 52486-074-000 | COLLAR, CUSHION RUBBER BUSH(SHOWA) | 2 | |
| 4 | 52486-KPL-902 | COLLAR, RUBBER BUSH(GABRIEL) | 2 | |
| 5 | 51500-KPL-901 | CUSHION ASSY., L. FR.(SHOWA) | 1 | |
| 5 | 51500-KPL-902 | CUSHION ASSY., L. FR.(GABRIEL) | 1 | |
| 6 | 52489-331-003 | RUBBER, A JOINT | 2 | |
| 6 | 52489-KPL-902 | BUSH, RUBBER(GABRIEL)(GIL) | 2 | |
| 7 | 90121-KPL-900 | BOLT, HEX., 8X32 | 2 | |
| 8 | 90443-KPL-900 | WASHER,SPECIAL, 8MM | 2 | |
