F-22-1 - WIRE HARNESS(SCV100G8)
HONDA Aviator SCV100G8 · 22 parts
Parts in This Assembly (22)
| Ref # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 30401-KVT-901 | CUSHION, C.D.I. UNIT | 1 | |
| 2 | 30410-KVT-901 | C.D.I. UNIT | 1 | |
| 3 | 30510-KVT-901 | COIL COMP., IGNITION | 1 | |
| 4 | 30604-KPL-841 | CAP, CORD WATER PROOF | 1 | |
| 5 | 30605-KPL-841 | SEAL, HIGH TENSION TERMINAL | 1 | |
| 6 | 30701-KPL-841 | BODY COMP., HIGH TENSIONTERMINAL | 1 | |
| 7 | 31600-KPL-901 | RECTIFIER ASSY., REGULATOR | 1 | |
| 8 | 32100-KVT-900 | HARNESS, WIRE | 1 | |
| 9 | 35012-KVT-900 | SWITCH ASSY. SET, COMBINATION & LOCK | 1 | |
| 10 | 35014-KVT-900 | KEY & SCREW SET | 1 | |
| 11 | 35121-KPL-841 | KEY, BLANK | 1 | |
| 12 | 38110-KVT-901 | HORN COMP. | 1 | |
| 13 | 38301-KPL-901 | RELAY COMP., WINKER | 1 | |
| 14 | 38306-GE7-000 | SUSPENSION, WINKER RELAY | 1 | |
| 15 | 38501-KPL-901 | RELAY COMP., STARTER(MULTILINK) | 1 | |
| 16 | 38506-KPL-900 | SUSP . START RELAY | 1 | |
| 17 | 90164-KEE-630 | SCREW FLAT 6X12 | 2 | |
| 18 | 95701-06012-08 | BOLT, FLANGE, 6X12 | 1 | |
| 19 | 95701-06016-00 | BOLT, FLANGE, 6X16 | 1 | |
| 20 | 95701-08012-00 | BOLT,FLANGE, 8X12 | 1 | |
| 21 | 96001-06018-00 | BOLT, FLANGE, 6 X 18 | 1 | |
| 22 | 98200-11000 | FUSE, A10 | 2 | |
