FOP-1-INNER BOX
HONDADio SCV100F3 · 18 parts
Parts in This Assembly (18)
| Ref # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 75581-KPL-900 | SET SPG LOCK KEY | 1 | |
| 2 | 81136-KRP-900 | BOX, INNER | 1 | |
| 3 | 81137-KRP-900 | PLATE, INNER BOX | 2 | |
| 4 | 81138-KRP-900 | HINGE A, INNER BOX | 2 | |
| 5 | 81139-KRP-900 | HINGE B, INNER BOX | 2 | |
| 6 | 81140-KRP-900 | BOX SET, INNER | 1 | |
| 7 | 81145-KPL-900 | KEY SET, INNER BOX | 1 | |
| 8 | 81161-KPL-900 | LID, INNER BOX B | 1 | |
| 9 | 81167-KPL-900 | PIN, INNER BOX B | 2 | |
| 10 | 87505-KRP-900 | LABEL, TIRE | 1 | |
| 11 | 90114-KPL-900 | BOLT, FLANGE, 5X16 | 4 | |
| 12 | 90156-KPL-900 | NUT, WELDING, 5X0.8 | 4 | |
| 13 | 93404-06025-07 | BOLT-WASHER, 6X25 | 1 | |
| 14 | 93891-05012-18 | SCREW-WASHER, 5X12 | 4 | |
| 15 | 93894-05025-08 | SCREW-WASHER, 5X25 | 4 | |
| 16 | 93903-24380 | SCREW TAPPING, 4 X 12 | 2 | |
| 17 | 94201-16151 | PIN, SPLIT, 1.6 | 2 | |
| 18 | 81157-KPL-900 | SEAL B, INNER BOX LID | 1 |
