F-9-REAR GRIP
HONDAEterno SC1504 · 11 parts
Parts in This Assembly (11)
| Ref # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 42702-KRB-900 | RIM COMP., WHEEL | 1 | |
| 2 | 42711-KRB-901 | TIRE (MRF) (3.50-10 4PR) | 1 | |
| 2 | 42711-KRB-903 | TIRE (CEAT) (3.50-10 4PR) | 1 | |
| 3 | 42712-KRB-901 | TUBE, TIRE (MRF) (3.50-10) | 1 | |
| 3 | 42712-KRB-902 | TUBE, TIRE (CEAT) (3.50-10) | 1 | |
| 4 | 81200-KRB-901 | GRIP COMP., RR. | 1 | |
| 5 | 81208-KPL-900 | RUBBER, RR. GRIP | 2 | |
| 6 | 83560-KRB-900 | HINGE, BODY COVER | 1 | |
| 7 | 90301-KBW-940 | NUT, CAP, 8MM | 3 | |
| 8 | 94050-06000 | NUT, FLANGE, 6 MM | 2 | |
| 9 | 95701-10020-00 | BOLT, FLANGE, 10X20 | 2 |
