F-19-SARI STEP
HONDAEterno SC1504 · 9 parts
Parts in This Assembly (9)
| Ref # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 83520-KRB-901 | STEP ASSY., SARI | 1 | |
| 2 | 83521-KRB-900 | PLATE, SARI STEP | 1 | |
| 3 | 83522-KRB-900 | STEP, PIN A, SARI | 1 | |
| 4 | 83523-KRB-900 | STEP, PIN B, SARI | 1 | |
| 5 | 83524-KPL-900 | SPRING, STEP | 1 | |
| 6 | 83530-KRB-901 | STEP COMP., SARI | 1 | |
| 7 | 94305-30142 | PIN, SPRING 3X14 | 1 | |
| 8 | 94305-30202 | PIN, SPRING 3X20 | 1 | |
| 9 | 95801-08045-08 | BOLT, FLANGE, 8X45 | 2 |
