F-37 - BATTERY
HONDA CBR250R CBR250RB · 14 parts
Parts in This Assembly (14)
| Ref # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 31500-KRY-801 | BATTERY ASSY MF7 | 1 | |
| 1 | 31500-KRY-971 | BATTERY ASSY ETZ7 | 1 | |
| 2 | 32401-KYJ-900 | CABLE, STARTER MAGNETIC | 1 | |
| 2 | 32401-KYJ-901 | CABLE, STARTER MAGNETIC BATTERY | 1 | |
| 3 | 32406-KAZ-000 | COVER, ST.MAG.TERMINAL | 1 | |
| 3 | 32406-KAZ-010 | COVER, STARTER MAGNETIC TERMINAL | 1 | |
| 4 | 35850-MR5-007 | SWITCH ASSY., STARTER MAGNETIC | 1 | |
| 5 | 35856-MBG-003 | RUBBER, SHOCK | 1 | |
| 6 | 80102-KYJ-900 | BAND COMP., BATTERY | 1 | |
| 7 | 80109-KYJ-900 | SPONGE, RUBBER | 1 | |
| 8 | 90111-MR5-000 | BOLT, SOCKET, 5X9 | 2 | |
| 9 | 95701-06012-08 | BOLT, FLANGE, 6X12 | 1 | |
| 9 | 95702-06012-08 | BOLT, FLANGE, 6X12 | 1 | |
| 10 | 98200-33000 | FUSE, BLADE(30A) | 2 | |
