F-5-30 - BRAKE PIPE
HONDA CB Hornet 160R CBF160MH · 15 parts
Parts in This Assembly (15)
| Ref # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 43311-K43-910 | PIPE COMP. A, RR. BRAKE | 1 | |
| 2 | 43312-K43-910 | PIPE COMP. B, RR. BRAKE | 1 | |
| 3 | 45127-K43-910 | PIPE COMP., FR. BRAKE | 1 | |
| 4 | 45128-K43-910 | PIPE COMP. B, FR. BRAKE | 1 | |
| 5 | 45129-K43-911 | HOSE COMP. B, FR. BRAKE | 1 | |
| 6 | 46300-MFG-D21 | VALVE ASSY., DELAY | 1 | |
| 7 | 46391-SDA-A01 | CLIP G, BRAKE PIPE | 3 | |
| 8 | 46400-K21-921 | PCV ASSY. | 1 | |
| 9 | 46410-K43-910 | STAY COMP., PCV | 1 | |
| 10 | 90145-GAZ-981 | BOLT, OIL, 10X22 | 1 | |
| 11 | 90545-300-000 | WASHER ,OIL BOLT | 2 | |
| 12 | 95701-06012-08 | BOLT, FLANGE, 6X12 | 2 | |
| 13 | 95701-06014-00 | BOLT, FLANGE, 6 X 14 | 2 | |
| 14 | 95801-06040-08 | BOLT, FLANGE, 6X40 | 2 | |
| 15 | 96001-06025-00 | BOLT, FLANGE, SH. 6 X 25 | 1 | |
