F-17 - SIDE COVER
HONDA CB Shine SP CBF125MG · 11 parts
Parts in This Assembly (11)
| Ref # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 83501-K67-900ZA | COVER, R. SIDE *NHB60M* MAT SELENE SILVER METALLIC | 1 | |
| 1 | 83501-K67-900ZE | COVER, R. SIDE *NH411M*FORCE SILVER METALLIC | 1 | |
| 2 | 83503-K67-920 | COVER, R. SIDE CBS | 1 | |
| 3 | 83510-K67-900ZA | SUB COVER, R. SIDE(WL) *TYPE1* | 1 | |
| 4 | 83601-K67-900ZA | COVER, L. SIDE *NHB60M* MAT SELENE SILVER METALLIC | 1 | |
| 4 | 83601-K67-900ZD | COVER, L. SIDE *NH411M*FORCE SILVER METALLIC | 1 | |
| 5 | 83602-K67-901 | SUB COVER, L. SIDE | 1 | |
| 5 | 83602-K67-900 | SUB COVER, L. SIDE | 1 | |
| 6 | 90101-GE0-000 | SCREW, HINGE PATCH | 2 | |
| 7 | 90104-KT2-000 | SCREW, SPECIAL, 6X14 | 2 | |
| 8 | 93903-24320 | SCREW, TAPPING, 4X12 | 8 | |
