F-14 - FUEL TANK(1)
HONDA CB Shine/ Shine 125 CBF125M7 · 24 parts
Parts in This Assembly (24)
| Ref # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 16950-KCC-901 | COCK ASSY., FUEL | 1 | |
| 2 | 17500-KTE-910ZA | TANK ASSY., FUEL(WL) *NHA04M* GENY GRAY METALLIC | 1 | |
| 2 | 17500-KTE-910ZB | TANK ASSY., FUEL(WL) *NH1* BLACK | 1 | |
| 2 | 17500-KTE-910ZC | TANK ASSY., FUEL(WL) *PB370M* CHAMPION BLUE METALLIC | 1 | |
| 2 | 17500-KTE-910ZD | TANK ASSY., FUEL(WL) *PB371M* MOON BLUE METALLIC | 1 | |
| 2 | 17500-KTE-910ZE | TANK ASSY., FUEL(WL) *RP175M* WILD PURPLE METALLIC | 1 | |
| 2 | 17500-KTE-910ZF | TANK ASSY., FUEL(WL) *R316M* ALPHA RED METALLIC | 1 | |
| 3 | 17506-KTE-910 | FILM, TANK PROTECTOR | 1 | |
| 4 | 17509-KTE-910 | FILM, TANK PROTECTOR | 1 | |
| 5 | 17611-KFN-850 | CUSHION, FR. FUEL TANK | 2 | |
| 6 | 17613-KTE-910 | RUBBER FUEL TANK RR | 1 | |
| 7 | 17614-KR3-000 | COLLAR FUEL TANK MT | 1 | |
| 8 | 17620-KSP-911 | CAP COMP., FUEL FILLER (JAY USHIN) | 1 | |
| 9 | 17681-KTE-910 | TUBE COMP., FUEL | 1 | |
| 10 | 37080-KTE-930 | FUEL UNIT SET | 1 | |
| 11 | 83551-376-000 | GROMMET, SIDE COVER | 2 | |
| 12 | 91305-443-740 | O RING, 39.5 X 5 | 1 | |
| 13 | 94050-06000 | NUT, FLANGE, 6 MM | 4 | |
| 14 | 95002-02080 | CLIP, TUBE | 1 | |
| 15 | 95002-50000 | CLIP, C9 TUBE | 1 | |
| 16 | 95701-08028-00 | BOLT FLANGE, 8 X 28 | 1 | |
| 17 | 16952-KTE-910 | SCREEN SET, FUEL STRAINER | 1 | |
| 18 | 16953-KTE-910 | CUP SET, FUEL STRAINER | 1 | |
| 19 | 16959-KTE-910 | FILTER, CUP | 1 | |
