F-11-1 - FRONT WHEEL(2)
HONDA CB Shine/ Shine 125 CBF125M7 · 24 parts
Parts in This Assembly (24)
| Ref # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 42713-KSP-901 | FLAP, TIRE(1.60/1.85-18) | 1 | |
| 2 | 44301-KPL-900 | AXLE, FRONT WHEEL | 1 | |
| 3 | 44311-KSP-900 | COLLAR, FR. WHEEL SIDE | 1 | |
| 4 | 44620-KSP-900 | COLLAR FR AXLE DIST | 1 | |
| 5 | 44635-KTE-920ZA | HUB SUB ASSY., FR. *NH35M* CLOUD SILVER METALLIC | 1 | |
| 6 | 44650-KTE-920ZA | WHEEL SUB ASSY., FR. *NH35M* CLOUD SILVER METALLIC | 1 | |
| 7 | 44680-410-000 | RETAINER, GEAR BOX | 1 | |
| 8 | 44701-KSP-930 | RIM, FR. WHEEL | 1 | |
| 9 | 44711-KFN-852 | TIRE, FR.(2.75-18 42P) | 1 | |
| 10 | 44712-KFN-852 | TUBE(2.75-18) | 1 | |
| 11 | 44800-KTE-920 | BOX ASSY., SPEEDOMETER GEAR | 1 | |
| 12 | 44804-KSP-901 | GEAR, SPEEDOMETER | 1 | |
| 13 | 44809-KPL-900 | WASHER, SPEEDOMETER GEAR | 1 | |
| 14 | 45122-KSP-930ZA | HUB, FR. BRAKE | 1 | |
| 15 | 45251-KSP-931 | DISK, FR. BRAKE | 1 | |
| 16 | 90105-MK5-010 | BOLT, FR., DISC, 8 X 22 | 6 | |
| 17 | 90302-KTE-911 | NUT FLANGE PT 6MM | 5 | |
| 18 | 90306-KTE-911 | NUT, CASTLE, 12 MM | 1 | |
| 19 | 91251-KPH-901 | DUST SEAL, 21 X 37 X 7 | 1 | |
| 20 | 91258-410-013 | DUST SEAL, 40X50X5(ARAI) | 1 | |
| 21 | 92911-06018-0E | BOLT, STUD, 6X18 | 5 | |
| 22 | 96140-63010-10 | BEARING, RADIAL BALL, 6301U | 2 | |
| 23 | 97388-41231-P0 | SPOKE SET A, 10X195.5 (INSIDE) | 18 | |
| 24 | 97490-41230-P0 | SPOKE SET A, 10X195 (OUTSIDE) | 18 | |
