F-11 - FRONT WHEEL(1)
HONDA CB Shine/ Shine 125 CBF125CA · 14 parts
Parts in This Assembly (14)
| Ref # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 42701-KTE-910 | RIM, RR. WHEEL(FOR FR.) | 1 | |
| 2 | 42713-KSP-901 | FLAP, TIRE(1.60/1.85-18) | 1 | |
| 3 | 44301-KPL-900 | AXLE, FRONT WHEEL | 1 | |
| 4 | 44311-KSP-900 | COLLAR, FR. WHEEL SIDE | 1 | |
| 5 | 44620-KSP-900 | COLLAR FR AXLE DIST | 1 | |
| 6 | 44635-KTE-910ZA | HUB SUB ASSY., FR. *NH35M* CLOUD SILVER METALLIC | 1 | |
| 7 | 44650-KTE-910ZA | WHEEL SUB ASSY., FR. *NH35M* CLOUD SILVER METALLIC | 1 | |
| 8 | 44711-KFN-852 | TIRE, FR.(2.75-18 42P) | 1 | |
| 9 | 44712-KFN-852 | TUBE(2.75-18) | 1 | |
| 10 | 90306-KTE-911 | NUT, CASTLE, 12 MM | 1 | |
| 11 | 91251-KPH-901 | DUST SEAL, 21 X 37 X 7 | 1 | |
| 12 | 96140-63010-10 | BEARING, RADIAL BALL, 6301U | 2 | |
| 13 | 97334-41166-P0 | SPOKE SET A, 10X163(INSIDE) | 18 | |
| 14 | 97600-41165-P0 | SPOKE SET A, 10X162.5(OUTSIDE) | 18 | |
