F-23-2 - SEAT(CB350DP/DSN/DSP)
HONDA HNESS CB350DSP/DSR · 17 parts
Parts in This Assembly (17)
| Ref # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 31501-K0Z-900 | BAND, BATTERY | 1 | |
| 2 | 50400-K0Z-910 | PIPE COMP., RR. GRIP | 1 | |
| 3 | 50710-K0Z-D01 | HOLDER ASSY., HELMET | 1 | |
| 4 | 53174-K0Z-900 | PLUG, 8MM | 2 | |
| 5 | 61104-428-010 | COLLAR, FR. FENDER(WHITE)..... (FOR RR.) | 2 | |
| 6 | 77105-K0Z-D00ZB | SEAT ASSY., FR. *TYPE1* | 1 | |
| 7 | 77205-KPP-T00 | RUBBER, SEAT SETTING | 4 | |
| 8 | 77207-K0Z-D00 | COLLAR, SEAT MOUNT | 2 | |
| 9 | 77305-K0Z-D00ZB | SEAT ASSY., RR. *TYPE1* | 1 | |
| 10 | 77315-K0Z-910 | STAY B, SET | 1 | |
| 11 | 84703-425-000 | RUBBER TAIL LIGHT (MOUNT) | 2 | |
| 12 | 90107-K0Z-900 | BOLT, BREAK OFF | 1 | |
| 13 | 90111-K0Z-900 | BOLT, SOCKET SPECIAL, 8X18 | 4 | |
| 14 | 90120-K0Z-900 | SCREW, PAN, 6X14 | 1 | |
| 15 | 90138-K0Z-910 | BOLT, FLANGE, 6X12 | 1 | |
| 16 | 90139-K0Z-910 | BOLT, FLANGE, 6X22 | 2 | |
| 17 | 95701-06030-08 | BOLT, FLANGE, 6X30 | 2 | |
